- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com.au
- Brand Name
- APC by Schneider Electric
- Product Line
- Easy UPS
- Product Type
- Double Conversion Online UPS
Easy UPS On-Line
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
For small to medium businesses, APC by Schneider Electric delivers a new category of UPSs designed for essential power protection needs even in the most unstable power conditions. APC Easy UPS 1 Ph Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range, inconsistent power conditions and delivering the quality millions of IT professionals trust around the world.
- Technical Information
- Plug/Connector Type
- IEC 320-C14
- Receptacle Type
- IEC 60320 C13
- Receptacle Detail
- 4 x IEC 60320 C13
- Overload Protection
- Yes
- Transfer Time
- 0 ns
- Phase
- Single Phase
- Application/Usage
- Equipment
- Server
- Power Description
- Load Capacity (VA)
- 1 kVA
- Load Capacity (Watt)
- 800 W
- Input Voltage
- 230 V AC
- Input Voltage Range
- 160 V AC - 280 V AC
- Output Voltage
- 220 V AC
- 230 V AC
- 240 V AC
- Input Frequency
- 70 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 600 J
- Management
- Network Management
- USB
- Alarm
- Low Battery
- Overload
- On Battery
- Controls/Indicators
- Status Indicators
LED Indicators:
- Provide Easy-to-read Status Of The Unit
- Utility Power Conditions.
LCD Graphics Display:
- Text and Mimic Diagrams That Display Modes of Operation
- System Parameters
- Alarms.
Control Panel:
- Multi-function LCD Status
- Control Console
- Interfaces/Ports
- Serial Port
- Yes
- USB (HID Compliant) Port
- Yes
- Battery Information
- Battery Characteristics
- Maintenance-free, Sealed, Leak-proof
- Battery Chemistry
- Lead Acid
- Battery Energy
- 1857.6 kJ
- Backup/Run Time (Full Load)
- 23.70 Minute
- Backup/Run Time (Half Load)
- 52 Minute
- Typical Battery Recharge Time
- 4 Hour
- Replaceable Battery
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -20°C - 50°C
- Maximum Operating Elevation
- 3 km
- Maximum Storage Elevation
- 14.76 km
- Storage Relative Humidity
- 0% - 95%
- Physical Characteristics
- Height
- 172 mm
- Width
- 438 mm
- Depth
- 412 mm
- Rack Height
- 4U
- Form Factor
- Rack-mountable
- Weight (Approximate)
- 27 kg
- Miscellaneous
- Environmentally Friendly
- Yes
