- General Information
- Manufacturer
- Dell Technologies
- Manufacturer Website Address
- http://www.dell.com.au
- Brand Name
- Dell
- Product Type
- AC Adapter
Fast, high-power charging in an efficient design
Powerful efficiency: Run your laptop and charge its battery at the same time with 280 watts of power delivery. This reliable adapter handles high-powered laptop usage while providing lightning-fast charging speeds. Powerful processing speeds travel easily with gallium nitride (GaN) technology which delivers more efficient current flow in a smaller and lighter form factor.
Sustainable design: Experience high-performance charging in a robust design. This is the Dell's only adapter featuring 80% recycled copper in the adapter cable. Designed with sustainability in mind, it incorporates 95% post-consumer recycled plastic in the adapter case and socket, as well as 98% recycled aluminium in the thermal shield.
Convenient connectivity: Connect effortlessly with a wide-range of compatibility across USB-C systems. The adapter comes bundled with a 5.9ft (1.8m) power cord, and a cable clip for easy cable management.
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Device Supported
- Notebook
- USB Type C Device
- Mobile Workstation
- Universal Adapter
- Yes
- Localization
- Australia
- New Zealand
- Cable Length
- 1.80 m
- Features
- GaN Technology
- Cables Included Detail
- 5.9ft (1.8m) Power Cord
- Interfaces/Ports
- USB Type-C
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Input Voltage Range
- 100 V AC - 120 V AC
- 200 V AC - 240 V AC
- Frequency
- 50 Hz
- 60 Hz
- Output Voltage
- 5 V DC
- 9 V DC
- 15 V DC
- 20 V DC
- 28 V DC
- 36 V DC
- 48 V DC
- Output Voltage Detail
- 5 V @ 3 A
- 9 V @ 3 A
- 15 V @ 3 A
- 20 V @ 6.5 A
- 28 V @ 5.893 A
- 36 V DC @ 5.83 A
- 48 V DC @ 5.83 A
- 12 V - 48 V @ 5.3 A
- Over-voltage Protection Range
- 9 V / 11 V
- 15 V / 17 V
- 20 V / 22 V
- 28 V / 30 V
- 36 V / 40 V
- 48 V / 50 V
- Maximum Output Power
- 280 W
- Maximum Input Current
- 4 A
- Maximum Output Current
- 7 A
- Output Current Limit
- 5 V / > 3 A
- 9 V / > 3 A
- 15 V / > 3 A
- 20 V / > 4 A
- 28 V / > 7 A
- 36 V / > 7 A
- 48 V / > 7 A
- Physical Characteristics
- Height
- 162.1 mm
- Width
- 78 mm
- Depth
- 23.1 mm
- Weight (Approximate)
- 698.5 g
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 35°C
- Minimum Storage Temperature
- -40°C
- Maximum Storage Temperature
- 70°C
- Maximum Operating Humidity
- 95%
- Maximum Non-operating Humidity
- 95%
- Maximum Operating Altitude
- 5 km
- Miscellaneous
- Package Contents
- 280W USB-C GaN AC Adapter
- 5.9ft (1.8m) Power Cord
- Cable Clip
- Compatibility
Dell Mobile Workstations:
- Pro Max 16 Plus MB16250
- Pro Max 18 Plus MB18250
- Certifications & Standards
- IEC
- EN
- UL 62368-1
- Post-consumer-waste%
- 95%
- Country of Origin
- China
